A More Productive Business Radio
Keep your teams connected with high quality communication and range.
Dedicated Channels for Enhanced Privacy
LMR frequency reduces crosstalk and static from other radio channels.
Easy to use and manage
Communicate instantly and manage talkgroups and subscriptions in real time. Maximize coverage, connections, and productivity without expanding infrastructure. Say goodbye to radio programming cables. Update an entire fleet over the air, without having to touch a single device.
Built for the job
Get all the benefits of WAVE PTX with a rugged two-way radio. Purpose built for business, everything about the TLK 150 is intentionally built. Never worry about rain, dust or extreme temperatures; TLK 150 is designed to perform in harsh working environments.
Safely operate in vehicles
Use the one button PTT microphone or take advantage of a variety of hands free accessories to operate safely on the road and stay within Federal Motor Carrier Safety Administration (FMCSA) regulations for driver distraction.
High quality nationwide push-to-talk
Communicate instantly with team members across the country at the push of a button. Bridge multiple job sites, facilities and operations without needing to set up or maintain a complicated infrastructure. Hear conversations clearly while on the road, no matter if communication is held through the compact microphone, visor microphone, or external speaker.
GENERAL SPECIFICATIONS |
|
| Network | 4G LTE, 3G |
| Channel Capacity | 96 Channels |
| Contact List | 300 contacts |
| Dimensions (H x W x L) |
6.65 in x 1.73 in x 3.66 in |
| (169mm x 44mm x 93mm) | |
| Weight | 1.41 lbs. |
| Voice Codec | OPUS |
| Wi-Fi | 802.11 a/b/g/n – 2.4 / 5.0 GHz |
| Bluetooth | Bluetooth V4.2 BR/EDR + BLE |
| GPS | GNSS / A-GPS |
| (GPS, GLONASS, Galileo, BeiDou) | |
| IP Rating | IP54 IEC60529 |
| Apps Supported | Powered by WAVE |
| Antennas | LTE antennas – External |
| GNSS antenna – External | |
| Wi-Fi/Bluetooth antenna – Internal | |
| Connectors | Front RJ45 connector for wired mobile microphone |
| Back antenna SMA connectors | |
| Back 20-pin MAP connector for other accessories | |
| Rated Audio | 4 W (Internal) |
| 16 W (External – 4 ohms) | |
| Audio Distortion @ Rated Audio | 3% (Typical) |
ENVIRONMENTAL SPECIFICATIONS |
|
| Operating Temperature | -4°F /+ 140°F (-20°C / +60°C) |
| Storage Temperature | -40°F /+ 185°F (-40°C / +85°C) |
| Thermal Shock | Per MIL-STD 810 |
| Humidity | Per MIL-STD 810 |
| ESD | IEC61000 – 4-2 Level 4 |
| Dust and Water Intrusion | IEC60529 – IP54 Cat 2 |
| Packaging Test | Per MIL-STD 810 |
APPLICABLE U.S. MILITARY SPEC RATINGS |
||
| MIL 810G STANDARD* | METHOD | PROCEDURES |
| Low Pressure | 500.5 | I, II |
| High Temperature | 501.5 | I, II |
| Low Temperature | 502.5 | I, II |
| Temperature Shock | 503.5 | I, II |
| Solar Radiation | 505.5 | I-C |
| Rain Blowing | 506.5 | I |
| Dust Blowing | 510.5 | I |
| Immersion | 512.5 | I |
| Vibration | 514.6 | I |
| Shock | 516.6 | I,IV |
| *Also meets equivalent MIL-STD-810-C, -D, -E and -F | ||
